COMPATIBILITY LIST

IEC-1000-4-2 Electrostatic discharges measurement was performed in the shielded enclosure according to the procedure set forth in the IEC 100-4-2: 1995 Part 4: Testing and measurement techniques. Section 2: Electrostatic Discharge Immunity Test

IEC-1000-4-3 Radiated radio-frequency electromagnetic field immunity measurement was performed in the 3m semi-anechoic chamber according to the procedure set forth in the IEC 1000-4-3: 1995 entitled Radiated radio-frequency electromagnetic filed immunity test.

IEC-1000-4-4 Electrical fast transient measurement was performed in the shielded enclosure according to the procedure set forth in the IEC 1000-4-4: 1995 entitled Part 4: Testing and measurement techniques. Section 4: Electrical Fast Transient/Burst Immunity Test.

IEC-1000-4-5 Surge immunity measurement was performed in the shielded enclosure according to the procedure set forth in the IEC 1000-4-5 Entitles Part 4: Testing and measurement techniques. Section 5: Surge Immunity Test.

IEC-1000-4-6 Immunity to conducted disturbance, induced by the radio-frequency fields measurement was performed in the shielded enclosure room according to the procedure set forth in the IEC 1000-4-6: 1995 entitled Part 4: Testing and measurement techniques. Section 6: Immunity to conducted disturbance, induced by radio-frequency fields

IEC-1000-4-8 Magnetic filed measurement was performed according to the procedure set forth in the IEC 1000-4-8: 1993 entitled :Part 4: Testing and measurement techniques. Section 8: Power frequency magnetic field immunity test.

IEC-255-5 Impulse Test measurement was performed in the shielded enclosure according to the procedure set forth in the IEC255-5.

IEC-1000-4-10 / IEC-255-22-1 IEC 1000-4-10: EMC Part 10. Testing and measurement techniques Section 10: Damp oscillatory magnetic fields immunity test.

IEC255-22-1: 1988. International Electrotechnical Commission (IEC) Electrical disturbance tests for measuring relays and protection equipment Part 1:1 MHz burst disturbance tests.

EN55022 EN55022: 1995-Class A (CISPR 22 Class A: 1995). Radio disturbance characteristic measurement for conducted and radiated emission was performed according to the procedure set forth in the EN55022: 1995 entitled "Limits and methods of measurement of radio disturbance characteristics of information technology equipment".

Our products were designed and manufactured to meet and survive 'real-world' operating environment for reliable and dependable field system operation.

Compatibility with various industrial standards for operating environment, power and electromagnetic interference are not compromised to ensure proper system operation on site.

They were subjected to a long list of tests to satisfy our customers needs and to ensure reliability over their service lifetime.

DATA COMMUNICATION PROTOCOL COMPATIBILITY

Native data protocols

IEC-870-5-101

IEC-870-5-103

IEC-870-5-104

Viscon-pd48

Other supported/emulated data protocols:

IEC61850

Extended WISP+

Harris HR2000

DNP 3.0

Modbus + Wave

SEL

ABB RP570/1

TLC 11M

TCP/IP - OPC

Others (customer specified).

Please call us to confirm availability of other supported data communication protocol.

IEC-60068-2-2-4-3 The environment tests were conducted according to IEC 60068-2-2: 1974 (+Supp. A: 1976 & Amd.1: 1993) Dry Heat Test Section two Test Bb: Dry heat for non-dissipating specimen with gradual change of temperature.

IEC-60255-5 Method of the tests were referred to IEC 60255-5: 1977 Electrical relays Part 5: Insulation test for electrical relays (Insulation resistance and dielectric test only). The tests were conducted at an ambient temperature of 25±5 °C.

IEC-60068-2-30-5 The environment tests were conducted according to IEC 60068-2-30 (12 + 12 hours cycle). Except for the environmental test condition, other tests were conducted at an ambient temperature of 25±5 °C

The test were conducted according to test clauses of IEC 60068-2-30: 1980 with the following modification and additions:-

- the environmental tests were conducted under high temperature of 43±3 °C, combined with cyclic humidity changes of 10%-95%-10%

- the other tests were conducted at an ambient temperature of 25±5°C

IEC-255-22-1 Surge immunity/impulse voltage measurement was performed in the shielded enclosure according to the procedure set forth in the IEC 61000-4-5/IEC 255-22-1 entitles Part 1: 1MHz burst disturbance test

IEC-255-5 Surge immunity/impulse voltage measurement was performed in the shielded enclosure according to the procedure set forth in the IEC 61000-4-5/IEC 255-5 entitles Part 5: Insulation tests for electrical relay. Clause 8: Impulse voltage test.

IEC-60255-21-1 Electrical Relays Part 21: Vibration, shock, bump and seismic tests onmeasuring relays and protection equipment. Section One â€“ Vibration tests (sinusoidal)

IEC-60255-21-1 Electrical Relays Part 21: Vibration, shock, bump and seismic tests on measuring relays and protection equipment. Section Two Shock and Bump tests

OTHERS

DD ENV 50204: 1995 Radiated radiofrequency electromagnetic filed â€“ Pulse modulated measurement was performed in the 3m semi-anechoic chamber according to the procedure set forth in the DD ENV 50204 entitled Radiated radio-frequency electromagnetic field - Pulse modulated.

Power Frequency Interference - The tests were carried out internally and witnessed by the personnel from Tenaga Nasional Berhad (ie. one of our main customer in Malaysia). The test description as the following:-

Common Mode: 500Vrms ±10%

Differential Mode: 250Vrms ±10%

Frequency: 50Hz ± 1%

Duration Test: not less than 2 seconds
